Intellectual Weighing Filling Machine
weight filling machine for big drum 200-300kg, for lubricant oil, chemical product.
Product Description
Description:
The TYPE CJ-1 weighing pneumatic filler, its principle is that weighing transduction platform set controlled volume under the control of the microcomputer program. As filling, at first remove the tare. When the materials are injected into vessel, at first quickly feed material at a large controlled volume, and then slowly modify the controlled volume at a small controlled volume. The operational person only need place the vessel on the platform, aim the vessel’s mouth at he material-falling mouth, in the moment, the program is started, the material-falling mouth downs, open the filling valve to feed material, when it reaches to the setting volume, automatically stop the material-replenishing, the material-feeding mouth ups, finished a filling process.
Main performance parameter :
|
Filling range （kg/barrel) |
100～1000 |
|
Drum size (mm) |
≦Φ600＊h980 |
|
Filling speed (barrel/h） |
70～30 |
|
Power （VAC） |
110/220 |
|
Accurate （F.S.） |
≦0.2% |
|
Air （kg/m2）
|
4～6 |
|
Division value（g） |
50、100、200 |
|
Size (mm) |
1600*1200*1600 |
|
Temperature |
0～45℃ |
