Pesticide Servo Piston Filling Machine

+
  • ZSP 12A 2L.jpg
  • 细节1.jpg
  • 细节2.jpg
  • 细节3.jpg

Suitable For Filling: Insecticide / Pesticide / Fertilizer / Chemicals / Agrochemical products / SC ...Etc kinds Products Filling Range : 50ml-1000ml Capacity Speed : 1000-6000BPH can be choosen No Leaking , No Bottle No Filling Less worker Meet GMP Standard

Suitable For Filling: Insecticide / Pesticide / Fertilizer / Chemicals / Agrochemical products / SC ...Etc kinds Products Filling Range : 50ml-1000ml Capacity Speed : 1000-6000BPH can be choosen No Leaking , No Bottle No Filling Less worker Meet GMP Standard

Product Description

Machine Name :  Full Automatic  Pesticide Servo Piston Filling Machine

Type: ZSP-A



Product description:

Time gravity filling machine is the most economical type of time filling machine for a limited range of applications.This time filling machine is best suited for liquids with very thin viscosities that do not change with ambient temperature or with batch variation.



The time filling machines work by a simple principle. Liquid is pumped into a holding tank above a set of pneumatically operated valves. Each valve is independently timed by the time flow filling machine master computer so that the precise amount of the liquid will flow by gravity into the containers, Independent timing of each filling valve/nozzle corrects for minor variations in flow rates so that each container is filled accurately. An automatic product level sensing float system detects level of the liquid to maintain pressure so that liquid can flow into containers fast and evenly. When liquid level is low, pump is on, liquid is pumped into holding tank, when liquid reaches high level, pump is off.



 This machine is a Gravity time control Type filling machine with high filling accuracy.

It applies 50ml-5000ml liquid for filling low viscous products .

It is widely use for agrochemical ECSL Filling Packing

It is produced with the GMP standards, safety, environmental hygienism, beautiful and adapt to different kinds of work place.





Suitable for Fill :





Details pictures :

Key Features :



 Heavy-duty stainless steel constructed

 Stainless steel Reservoir

 Automatic Bottling Index kit with bottle counter

 Pneumatic indexing gates (count in, count out)

 Automatic product level sensing float system

 Easily adjustable nozzle height settings accommodate vials to gallons

 User friendly PLC controls with touch screen HMI

 No bottle/No fill sensor

 Bottle backup sensor (downstream) delays operation until jam is cleared

 Able to output multiple doses per container for large containers

 Easy clean stainless steel quick connect fittings

 Drip Tray

 Diving heads nozzles for bottom up filling to reduce foam

 Neck grabbers for containers with small opening

 Specifications are subject to change without notice, All rights are reserved.



How to choose automatic piston filling machine is big challenge for customers, If your are unsure how to choose a piston filling machine,Please let me know

 What product to fill

 What output capacity to achieve

 What material and shape of containers

 What size of containers to fill

Our professional team will help you to choose

So please contact us for specific advice on the best solution for you now.
